Description
Product Features:
-Be suitable for all kinds of pressure sensors, and display the value of oil pressure
-Use moving-magnet principle to drive the needle, featuring good endurance and anti-vibration.
-IP67 waterproof and dustproof grade
-Stepper motors used for full range of stepping gauges, great feature with its less power consumption, longer life, higher precision, etc.
-With curved glass (with anti-fogging function)
-With ultra-wide working voltage design( long-term operating voltage: 9-32V, Maximum up to: 36V (≤ 1 min)).
Technical Data:
-Fixing dimension: 52mm(2")
-Indicating Range:0-5Bar 0-10Bar
-Signal: 10-184ohm
-Working Voltage: 9-32V(12V/24V)
-Backlight: Red
-Operation mode: LCD display, stepper motor
Package Includes:
1x Digital Oil Pressure Gauge
1x Multi-plug socket
1x Installation Instruction
