Description
Features:
-Oil Pressure: 0-10 bar/0-145psi (Pressure sensor: 10-184ohm)
(After power on, press the back button to adjust unit, if the oil pressure unit is "psi", the temperature unit will be "℉".)
-Water Temperature: 0-120℃/0-250℉ (signal : 1600-22ohm)
(The water temperature is displayed by default. If you need oil temperature, please contact us to customize.）
-Voltmeter: 9-32V
-Fuel Level: 0-100% (Press the back button to adjust the level signal: 0-190Ω/240-33Ω available. )
-Sensor Fault Alarm (Chinese and English can be switched)
-Degree of Protection: IP67
-Backlight: TFT Screen
* Sensor are not provided with this gauge.
* Pls. order the sensor separately if you need it.
Dimensions:
-85mm diameter (3-3/8")
-55mm Depth (2-3/4")
Package Included:
1*4 in 1 Gauge
1*multi-plug socket
1*Instruction
