Description
Display Function:
1. Multi functions display: clock, battery voltage, altitude, satellite numbers, mileage, trip time.
2. Light sensor: HUD can automatically adjust the brightness according to the environment.
3. Driving direction: N-North, S-South, W-West, E-East. It will display when the car is in driving.
4. Speed: display the vehicle driving speed in digital number.
5. Speed unit: KM/H=kilometer/hour, MPH=Mile/hour.
6. Clock and driving time icon.
7. Mileage: display the single driving distance for this trip.
8. Altitude: current altitude.
9. Satellite signal icon: it will flash for searching signal,and will stop once searching the satellite signal successfully.
Technical Parameters:
1.Environment temperature: - 40℃— +80℃
Barometric press: 86-106KPa
Relative humidity: 10%-95%
Environment voice: <=60dB
2.Work voltage: 5V~28Vdc(12Vdc/200mA)
3.Sleep current: <=30mA
4.Product size: fold 135X68X30 mm,full size:135x68x56mm
5.Projector image size: 90x20mm
6.Display way: projector
7.Display channel: LED Display
8.Reflector transmittance: 96%
9. Virtual image distance: 55 mm
10: Left and right angle view: 60°
11. downwards angle view: 15°
