Description
Features:
-Water Temperature: 0-120℃ (signal : 1600-22ohm)
-Oil Pressure: 0-10 bar (Pressure sensor: 10-184ohm)
-Fuel Level: 0-100% (Press the back button to adjust the level signal: 0-190ohm/240-33ohm available.)
*Sensor are not provided with this gauge.
*Plz. order the sensor separately if you need it.
-Voltmeter: 9-32V
-Alarm: Symbal flashing(When 2 or more faults occur, an item is reported every 3s.)
-Degree of Protection: IP67
-Backlight: TFT Screen
Dimensions:
-52mm diameter (2")
-55mm Depth (2-3/4")
Package Included:
-1*3 in 1 Multi-function Gauge
-1*Multi-plug socket
-1*Instruction
